Epoxy FR4
Basic Information:
Brand:JingHong
Materials: 7628 Electronic Cloth + Epoxy Resin
Grade: UL94V0,NEMA
Nature Color: Light Green
Thickness: 0.3mm --- 100mm
Regular Size: 1020mm*1220mm,1220mm*2440mm,1020mm*2020mm
Custom Size: 1030mm*2030mm,1030mm*1030mm 1030mm*2070mm
Packaging: Regular packing, Protect by Pallet
Productivity: 30000 Tons per year
Transportation: Ocean, Land, Air
Payment:T/T
MOQ:500KG
- Fast Delievery
- Quality Assurance
- 24/7 Customer Service
Product Introduction
Product Introduction
Hebei Jinghong Electronic Technology Co., Ltd. was established in 2018, occupying a site area of 36,300 square meters with a building area of 26,000 square meters. With a total investment of 191 million yuan, the company specializes in the R&D, production, and sales of insulating materials including 3240 epoxy boards, FR-4 boards, bakelite boards, water-green fiberglass boards, and phenolic cloth boards, boasting an annual production capacity of 30,000 tons. The company is an integrated new materials production and processing enterprise encompassing scientific research, development, manufacturing, sales, and service. It has obtained certifications for Quality Management Systems, Environmental Management Systems, and Occupational Health and Safety Management Systems.
Epoxy FR4 Production Description
Epoxy FR4 are solid, high strength laminates consisting of fiberglass pregnant reinforced with high strength epoxy resin. In general, the insulation sheet is applied to power generation equipment, power transmission equipment, communication equipment, new energy industry, and use in the fields of electronics, electrical appliances, motors, etc.
Improve and Innovation
With the development of the market, the power system has developed from the original low voltage to high voltage, and the transmission of electric power has developed from short distance to long distance, which has stricter quality requirements for the insulation materials used.
What we are going to do is to make constant endeavors, and adhere to innovative spirits timely understand industrial dynamics, market demand and client requirements, and provide products with the highest quality and most competitive price to clients. The direction of the development of Epoxy FR4 mainly focuses on: high pressure resistance, impact resistance, corrosion resistance, water resistance, turbidity resistance, cryogenic resistance, radiation resistance and ultra-high flame resistance.
1. Test Jig
2. Fixture PCB Testing Jig
3. Insulation Plate
4. Switch insulation Plate
5. Polish Gear
6. Mould in Cloth and Shoes
7. Insulation Part of Bakelite Sheet
8. Lithium Battery Pack
Technical Data for FR4
NO | TEST ITEMS | UNIT | TEST RESULT | TEST METHOD |
1 | Bending Strength Perpendicular to Laminations | MPa | 571 | GB/T 1303.4-2009 |
2 | Compressive Strength Perpendicular to Laminations compressive | MPa | 548 | |
3 | Parallel Layer Impact Strength (Simply Supported Beam, Gap) | KJ/m² | 57.3 | |
4 | Tensile Strength | MPa | 282 | |
5 | Vertical Layer Breakdown Voltage (90℃ + 2℃, 25# transformer oil, 20s step by step boost, φ25mm/φ75mm cylinder electrode system) | kV/mm | 16.7 | |
6 | Parallel Layer Breakdown Voltage (90℃ + 2℃, 25# transformer oil, 20s step by step boost, φ130mm/φ130mm flat plate electrode system) | kV | ＞100 | |
7 | Relative Permittivity (50HZ) | - | 5.40 | |
8 | Dielectric Dissipation Factor (50HZ) | 7.2*10-3 | ||
9 | Insulation Resistance after Soaking | Ω | 2.2*1013 | |
10 | Density | g/cm3 | 2.01 | |
11 | Water Absorption | mg | 5.3 | |
12 | Barcol Hardness | - | 76 | GB/T 3854-2005 |
13 | Flammability | Grade | V-0 | GB/T 2408-2008 |
REMARK:1. NO.2 the sample height is (5.00~5.04) mm; 2. NO.5 the sample thickness is (2.02~2.06) mm; 3. NO.6 the sample size is (100.50~100.52)mm*(25.10~25.15)mm*(5.02~5.06)mm thickness, The electrode spacing is (25.10~25.15)mm; 4. NO.11 the sample size is (49.86~49.90)mm*(49.60~49.63)mm*(2.53~2.65)mm; 5. NO.13 the sample size is (13.04~13.22)mm*(3.04~3.12)mm thickness. | ||||
Our strength
1. The annual production capacity of the factory is 43,000 tons, which is one of the largest insulation board manufacturers in China
2. Fully automated production workshop, product quality is stable
3. We have more than 20 years of experience in producing and selling insulating sheet, Cooperate with a number of domestic and foreign trading companies for many years.
4. Professional foreign trade team can provide perfect services
5. Have our own logistics company, provide one-stop service
Production Process
|
Packaging and Shipping
Regular packing, Protect by Pallet
